THIELE supplies pneumatic and hydraulic saws for use underground. These can be employed not only as chain saws but also for cutting other items such as pipes and roadway supports up to a diameter of 180 mm.
-
-
Mining
- Chains
- Chain Grades
- Connectors
- Flight Bars
- Assemblies
- Accessories
- Contact
-
Industry
- Lifting Technology
- Load Securing
- Application Engineering
- Light Material Handling
-
Conveying of Bulk Material
-
Mining
- Company
- Career
Chain Saws
Chain saws (hydraulic)
Properties
Article-No. | Cutting Ø [mm] | Cutting □ [mm] | Power [kW] | Operating [bar] | Oil [l/min] | Quick [mm] | Overall [mm] | Housing | Sound [dB(A)] | Vibration [m/s²] | Weight [Kg] |
Z10206 (6043) | 107 | 107x120 | 1.5 | 140 | 15-50 | 1/2“ FF | 550 | E-Stahl | 81.7 | 2.6 | 10.0 |
Z10228 (6042) | 120 | 120x180 | 1.5 | 140 | 15-50 | 1/2“ FF | 630 | E-Stahl | 81.4 | 2.8 | 10.4 |
Z08368 (6041) | 180 | 180x180 | 1.5 | 140 | 12-50 | 1/2“ FF | 730 | E-Stahl | 81.7 | 2.7 | 13.5 |
Z10229 (6054) | 180 | 180x240 | 1.5 | 140 | 12-50 | 1/2“ FF | 838 | E-Stahl | 81.5 | 2.7 | 16.1 |
Technical specifications subject to change; Performance data for operating pressure of 140 bar | |||||||||||
